Automatic CLI

Image generated with DALL-E

Soleil offers three main ways to create CLIs from solconf files:

1. by means of the builtin solex script that enables calling any solconf file directly,

2. by means of the @solex decorator that turns any function into a CLI,

3. or by adding an argument of type SolConfArg to a standard argparse Python parser.

All of these methods support overriding values within the solconf package directly from the command line using override strings in familiar Python syntax, for example:

$ solex ./my_conf.solconf a=1 b=2

The second and third method further support mixing solconf objects with standard argparse command line options:

$ my_script --opt1 \
> --solconf-arg-1 ./my_conf1.solconf a=1 b=2 \
> --solconf-arg-2 ./my_conf2.solconf a=1 b=2

Besides this, solconf files can also be loaded directly from Python scripts and overriden using dictionaries of Python objects:

>>> from soleil import load_solconf
>>> obj = load_solconf('./my_conf.solconf', overrides=[{'a':1, 'b':2}])

solex script

Soleil configuration files resolve to an object or function call specified by the as_type member. This resolution can be invoked from the command line directly using the builtin solex script.

For example, the train.solconf example discussed in the Getting Started section can be invoked from the command line as follows:

$ solex ./train.solconf

100%|██████████████████████████████████████████████| 170498071/170498071 [00:15<00:00, 10742265.75it/s]
Extracting /tmp/soleil_examples/cifar/cifar-10-python.tar.gz to /tmp/soleil_examples/cifar
[1,  2000] loss: 2.175
[1,  4000] loss: 1.856
[1,  6000] loss: 1.674
[1,  8000] loss: 1.588
[1, 10000] loss: 1.544
[1, 12000] loss: 1.475
[2,  2000] loss: 1.430
[2,  4000] loss: 1.398
[2,  6000] loss: 1.373
[2,  8000] loss: 1.342
[2, 10000] loss: 1.327
[2, 12000] loss: 1.304
Finished Training

CLI overrides

Optionally, we can override the values of any of the variables accessible from the root configuration directly through the solex invokation. For example, to change the learning rate and batch size, we could use

$ solex ./train.solconf optimizer.lr=1e-4 data.dataloader.batch_size=8

The overrides must be valid Python statements that are first interpreted by the bash interpreter. So, to assign a string, we could use two sets of enclosing quotation marks, for example:

$ solex ./train.solconf data.dataset.root='"~/my_root"'

Under the hood, Soleil evaluates these string override statements using a modified Python parser that supports a subset of the Python syntax including all builtin literal values and operators.

See the Overriding Configurations section for other override options.

Available variables

The solex script includes an experimental --show flag that skips object resolution and instead displays all the variables accessible from the root configuration:

$ solex ./train.solconf --show

{
 "type:{'as_type': True, 'hidden': False, 'cast': <function <lambda> at 0x7f995ed17310>}": 'soleil_examples.cifar.train:train',
 'net': {"type:{'as_type': True, 'hidden': False, 'cast': <function <lambda> at 0x7f995ed17310>}": 'soleil_examples.cifar.model:Net'},
 'optimizer': {
     "type:{'as_type': True, 'hidden': False, 'cast': <function <lambda> at 0x7f995ed17310>}": 'torch.optim:SGD',
     'params': 'soleil.special.resolved:resolved<<resolved.parameters())>>',
     'lr': 0.001,
     'momentum': 0.9
 },
 'criterion': 'CrossEntropyLoss()',
 "data:{'hidden': True}": {
     'transform': 'Compose(\n    ToTensor()\n    Normalize(mean=(0.5, 0.5, 0.5), std=(0.5, 0.5, 0.5))\n)',
     'dataset': {
         "type:{'as_type': True, 'hidden': False, 'cast': <function <lambda> at 0x7f995ed17310>}": 'torchvision.datasets:CIFAR10',
         'root': '/tmp/soleil_examples/cifar',
         'train': 'soleil.overrides.req:req<<soleil.overrides.req.req object at 0x7f98959b1c40>>',
         'download': True,
         'transform': 'Compose(\n    ToTensor()\n    Normalize(mean=(0.5, 0.5, 0.5), std=(0.5, 0.5, 0.5))\n)'
     },

     ...

The output produced with this --show will be improved in later versions.

Note

Like solex-based CLI invokations, Soleil CLIs built with the @solex() decorator or using a SolConfArg type in a Python argparse parser all suport CLI overrides. Overrides with non-string values can also be specified when loading a module with load_solconf() from a Python script. See Overriding Configurations for more information.

Running a method

Sometimes, we might want to invoke a method of an object built by the as_type member of a solconf module. For example, given a Python package experiment containing class Experiment,

# experiment/__init__.py

class Experiment:

  param1:int
  param2:int

  def train(self):
      ...

  def eval(self):
      ...

we might be interested in calling its train() method. The solex script supports doing so by means of the as_run modifier:

# train.solconf

# Lets solex know to call the train method of
# the built Experiment instance
run:as_run = lambda exp_obj: exp_obj.train()

# Builds an Experiment instance
type:as_type = 'experiment.Experiment'
param1 = 1
param2 = 2

Invoking solex on this script will first instantiate the Experiment class and then invoke the as_run member on the resulting instance – in this case, the as_run member calls the train method on the built Experiment instance.

Other solex options

The solex script includes other useful functionality such as (--profile) the ability to profile the code run by the script, (--pdb) break into a debugger if an exception occurs or (--show) explore the configuration without resolving it.

>> solex -h

usage: solex [-h] [--profile [DO_PROFILE]] [--pdb] [--show] conf [conf ...]

Executes a configuration file.

positional arguments:
  conf                  The path of the configuration file to launch and, optionally, any argument overrides

optional arguments:
  -h, --help            show this help message and exit
  --profile [DO_PROFILE]
                        Profile the code and dump the stats to a file. The flag can be followed by a filename ('solex.prof' by default)
  --pdb                 Start an interative debugging session on error
  --show                Display solconf module without resolving and exit

@solex() decorator

The @solex decorator can be used to convert any Python function into a CLI script that takes an object retrieved from a solconf root config as its first argument:

from soleil.cli_tools import solex
import climax as clx

@solex()
@clx.argument('--my-opt', default=0, type=int, help='My optional argument.')
def foo(obj, my_opt):
    """ Optional doc string will override the default. """
    ...

if __name__=='__main__':
   foo()

While not required, the example above makes use of the excellent climax module that provides a convenient argparse interface. One can use @solex in place of the @climax.command decorator and subsequently decorate the function using any of the composable climax decorators – in the example above we add an optional CLI argument --my-opt in this way.

One can also make the generated command part of a command group by specifying the climax group in the decorator as follows:

# /usr/bin/env python
# File './my_script'

import climax

@climax.group()
def main():
    ...

@solex(main)
def train(obj):
    ...

@solex(main)
def eval(obj):
    ...

if __name__=='__main__':
   foo()

The resulting CLI contains two subcommands that can be invoked as follows (assuming the path of the above script is ./my_script):

$ ./my_script train
$ ./my_script eval

All of the above can also be done using standard argparse method calls directly instead of the climax interface by retrieving the ArgumentParser object from the decorated function:

>>> foo.parser
ArgumentParser(...)

argparse parsers

Soleil supports adding described objects as Python ArgumentParser arguments. Such objects will be instantiated from the description of a solconf root config. Supplying overrides is likewise supported.

Given a standard Python parser:

>>> import argparse
>>> parser = argparse.ArgumentParser()

An argument whose value will be obtained by resolving a Soleil root config can be added by setting the type keyword of that new argument to an instance of SolConfArg:

>>> from soleil.cli_tools import SolConfArg
>>> parser.add_argument("new_arg", type=SolConfArg())
ReduceAction(...)

When SolConfArg is initialized with no arguments, the source config will need to be specified from the CLI:

>>> parser.parse_args([f"{soleil_examples}/vanilla/main.solconf"])
Namespace(new_arg={'a': 1, 'b': 2, 'c': 3})

Alternatively, we can specify the source config in the SolConfArg initialization

>>> parser = argparse.ArgumentParser()
>>> parser.add_argument("new_arg", type=SolConfArg(soleil_examples/"vanilla/main.solconf"))
ReduceAction(...)
>>> parser.parse_args([])
Namespace(new_arg={'a': 1, 'b': 2, 'c': 3})

In either case, any extra CLI arguments will be interpreted as an override:

>>> parser.parse_args(["a=10", "c=30"])
Namespace(new_arg={'a': 10, 'b': 2, 'c': 30})

See the documentation of SolConfArg for more information.
